This video show how to install UTFT library (from ) and test example on Arduino Mega 2560.
provided 12-examples with Arduino ,3-examples with STM32 . Compatible with UTFT / UTFT_Buttons /Utouch Library for arduino. Compatible with Arduino-Series development Board. Compatible with 3.3/5V operation voltage level. OnBorad level conversion chip for 5V/3.3V MCU. Support Arduino Mega2560 Directly inserted. Moreover, this module includes the 5V -3.3V power conversion circuit and Level Level conversion circuit, This Module can Directly inserted into the Arduino Mega2560 Board, it also includes the SD card socket and SPI FLASH circuit.
The controller of this LCD module is HX8357B, it supports 16-wires DataBus interface. QD320DB16NT8357RA module is 3.2" TFT LCD with 262K color 480x320 resolutions.
